Hastelloy C276 Wire
Hastelloy C276 is a nickel-based corrosion-resistant alloy, which is mainly divided into two categories: nickel-chromium alloy and nickel-chromium-molybdenum alloy. Hastelloy C276 has good corrosion resistance and thermal stability, and is mostly used in aviation, chemical fields, etc. It is composed of elements such as Ni, Cr, Mo, Fe, Si, etc. It is Ni-Mo series, Ni-Cr-Mo series and Ni-Si series corrosion-resistant and heat-resistant alloys in nickel-based alloys. Its density 9.2g/cm, melting point 1330-1380℃, magnetic permeability≤1.001(℃, RT).
Description
Product Description
A Ni-Cr-Mo super alloy Hastelloy C276 Wire offers great resistance in the strong acidic and alkali media and prevents pitting, crevice corrosion and SCC. Hastelloy C276 also offers wide resistance to wet chloride gas, hypochlorite and chlorine dioxide media.
Hastelloy C-276 prevents the localized and intergranular corrosion in the presence of strong acids such as sulfuric acid, phosphoric acid, hydrochloric acid, nitric acid and organic acid. It provides excellent corrosion resistance to the entire magnitudes of sulfuric acid up to 95oC or 200oF. For chloride concentrations about or above 0.1% and of pH 2, alloy C276 is fit for use.
Characteristics of Hastelloy C276 Wire
* Excellent corrosion resistance in reducing environments
* Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
* High nickel and molybdenum contents providing good corrosion resistance in reducing environments
* Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
* Resistance to localized corrosion such as pitting and stress-corrosion cracking
* One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide
Hastelloy C-276 Specifications
|
Wire |
Sheet |
Strip |
Pipe |
Rod |
Fittings |
|
ASTM B574, ISO 9723. ISO 9724, DIN 17752. DIN 17753, DIN 17754 VdTüV 400/12.98, Filler Metal C276, AWS A5.14 ERNiCrMo-4, AWS A5.11 ENiCrMo-4 |
ASTM B575, ASTM B906, ISO 6208, DIN 17750, VdTüV 400/12.98 |
ASTM B575, ASTM B906, ISO 6208, DIN 17750, VdTüV 400/12.98 |
ASTM B622, ASTM B619, ASTM B775, ASTM B516, ASTM B626, ISO 6207, DIN 17751, VdTüV 400/12.98 |
ASTM B574, ISO 9723. ISO 9724, DIN 17752. DIN 17753, DIN 17754 VdTüV 400/12.98 |
ASTM B366, DIN 17744 |
Applications of Hastelloy C276 Wire
* Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
* Flue gas desulfurization systems
* Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
* Sour gas wells
* Pulp and paper production
* Waste treatment
Forms Available
|
Hastelloy C276 Alloy Wire |
Hastelloy C276 Alloy Wire Mesh |
|
Hastelloy C276 Alloy Strip/Foil |
Hastelloy C276 Alloy Sheet/Plate |
|
Hastelloy C276 Alloy Rod/Bar |
Hastelloy C276 Alloy Pipe/Tube |
|
Hastelloy C276 Alloy Flanges |
Hastelloy C276 Alloy Foil |
