Customized UNS N05500 Monel K500 Nickel‑Copper Alloy For Oil And Gas Applications

Monel K500 (UNS N05500 / W.Nr. 2.4375 / AMS 4676) is a precipitation-hardenable nickel-copper alloy that delivers the perfect balance of high strength and exceptional corrosion resistance for the most demanding oil and gas applications. By adding aluminum (2.30–3.15%) and titanium (0.35–0.85%) to the nickel-copper base, Monel K500 achieves age-hardening capability that delivers approximately three times the yield strength and double the tensile strength of Monel 400.

What sets our UNS N05500 Monel K500 Nickel‑Copper Alloy apart is our customization capability – we don't just supply standard stock; we deliver precision-engineered components tailored to your specific oil and gas application requirements, from raw material selection through to final machining and heat treatment.

Standard Note: Round bars comply with ASTM B865, plates conform to ASTM B127, seamless tubes follow ASTM B165. Custom‑machined semi‑finished blanks are produced against customer drawings, with dimensions and tolerances confirmed via technical agreement.

Source: ASTM B865 / UNS N05500 specification

• Density: 8.44 g/cm³
• Age‑hardened tensile strength: 1035‑1240 MPa
• Good resistance to brine, seawater and mild sour‑service environments
• Outstanding fatigue strength under cyclic vibration and torsion
• Low magnetic permeability
• Multiple temper options: annealed, cold‑worked, age‑hardened

Custom‑size round bar, flat bar, hex bar (ASTM B865)

Cut‑to‑length plate, sheet and strip blanks (ASTM B127)

Custom seamless tube / pipe (ASTM B165)

Forging stock, semi‑finished machined parts per drawings

Superior Corrosion Resistance

• Seawater corrosion rate ≤0.0025mm/year
• Chloride stress corrosion cracking resistance – 8–10× better than 304 stainless steel
• H₂S resistance – Survives H₂S >2,000 ppm + CO₂ at 150°C (302°F) per NACE TM0177
• Excellent resistance to hydrofluoric acid, sulfuric acid, and chlorides
• Virtually immune to chloride stress corrosion cracking

Non-Magnetic

Monel K500 remains virtually non-magnetic down to -101°C (-150°F) , making it ideal for non-magnetic drill collars and instrumentation housings.

Unmatched Strength

Monel K500 delivers yield strength ≥690 MPa and tensile strength ≥965 MPa after precipitation hardening. Under optimal aging conditions, tensile strength can reach 1100 MPa with yield strength up to 790 MPa. This is approximately 3× the yield strength of Monel 400.

High-Temperature Performance

• Retains >82% of strength at 315°C (600°F)
• Stable tensile properties up to 650°C (1200°F)
• -196°C (-321°F)toughness – No ductile-to-brittle transition

We understand that every oil and gas project has unique requirements. That's why we offer end-to-end customization:

• Material Forms Available

• Heat Treatment Options

• Value-Added Machining Services

We provide precision machining to reduce your secondary processing costs:

• Bar: Cut-to-length, rough turning (h11/h9), chamfering, centre drilling, stepped shaft pre-machining
• Forgings: Rough turning/milling per drawing, UT inspection surface preparation
• Plate: Cut-to-size, CNC waterjet/plasma cutting, bolt hole pre-drilling, levelling

Get Quote

Client Background

A Russian oil‑and‑gas equipment manufacturer supplies subsea auxiliary assemblies for coastal offshore projects. They needed customized Monel K500 semi‑finished blanks for pump‑shaft and fastener components, which run under combined loads of seawater erosion, brine corrosion and cyclic torsional stress.

Main Difficulties

• Strength limitation of Monel 400: Their initial trial using Monel 400 met corrosion requirements, yet insufficient yield strength created hidden risks of shaft deformation under peak working torque.
• Multi‑form customized procurement: The project required both age‑hardened round‑bar blanks for pump shafts and small‑diameter seamless tubing for internal cooling structures. Most suppliers could only deliver standard bars without custom tube processing capability. Separate sourcing brought inconsistent heat‑treatment quality and longer lead‑time.
• Strict material documentation requirement: Critical safety spare‑parts required mill test certificates, and optional third‑party PMI and salt‑spray inspection reports for material validation.
• Precise customization tolerance: Blanks needed non‑standard lengths and reserved machining allowance, requiring strict dimensional control during cutting.

Our Solutions

Our technical team recommended customized age‑hardened UNS N05500 Monel K500 and provided a one‑stop tailored supply plan:

• Supplied ASTM B865 certified hot‑finished round bars with tightly controlled age‑hardening heat treatment parameters, to guarantee stable high mechanical strength and anti‑fatigue performance under cyclic torsional load.
• Delivered customized seamless tubes manufactured in compliance with ASTM B165, adopting unified batch management with bar materials to ensure consistent metallurgical quality.
• Each shipment came with complete mill test certificates, covering chemical composition, mechanical indicators and heat‑treatment records. As requested by the client, we arranged ISO‑17025 accredited third‑party lab tests for PMI identification and salt‑spray corrosion verification.
• Completed custom cutting according to drawings, reserved proper machining allowance and consolidated all items in one shipment.

Project Outcomes

• Pump‑shaft blanks fully satisfied design strength specifications, eliminating torsional deformation risk in long‑time offshore operation.
• Samples successfully passed salt‑spray corrosion testing with no obvious corrosion defects.
• One‑stop customized supply shortened the overall material lead‑time by approximately 22%.
• Complete inspection documents simplified their incoming inspection and component certification workflow. Following the successful trial production, this oil‑gas client has placed repeated bulk orders for serial manufacturing.

Customized Monel K500 (UNS N05500) is the material of choice for the most demanding oil and gas applications – from downhole drill collars and MWD/LWD tool bodies to pump shafts, valve components, and subsea equipment. Its unique combination of high strength (≥965 MPa tensile), exceptional corrosion resistance (especially in seawater and H₂S environments), non-magnetic properties, and low-temperature toughness makes it indispensable for offshore drilling, sour gas production, and subsea engineering.

• Downhole Drilling Tools

Monel K500 is widely used for oil-well drill collars and instrumentation components. Its non-magnetic properties make it ideal for MWD/LWD (Measurement While Drilling / Logging While Drilling) tool bodies. The alloy also serves as drill bit components, sucker rods, and downhole safety valves in offshore and high‑sulfur oil and gas wells.

• Pump Shafts & Impellers

Monel K500 is the preferred material for pump shafts and impellers in centrifugal pumps for the oil and gas industry. It is particularly well suited for centrifugal pumps because of its high strength and low corrosion rates in high-velocity seawater. In oilfield electrical submersible pumps (ESP), Monel K500 is used for pump shafts, pump head and base fasteners, and wireline tool threaded adapters.

• Fasteners & Bolting

Monel K500 fasteners – bolts, nuts, studs, and springs – provide exceptional strength and corrosion resistance in offshore drilling towers and marine service environments. Our customized fasteners range from M6 to M120 with 6H thread accuracy, compatible with metric/imperial standards.

• Offshore & Subsea Equipment

Monel K500 is extensively used in offshore platforms, subsea pipelines, and seawater desalination equipment. Offshore sites in the North Sea, Gulf of Mexico, and West Africa have demonstrated that Monel K500 works exceptionally well in severe service conditions, including exposure to produced water with high chloride content and hydrogen sulfide.

• Valves & Fittings

Monel K500 valve components – including valve stems, valve trim, safety lifts, and valve bodies – ensure reliable operation even under extreme pressures and temperatures. A recent case involved a subsea gas injection system operating at 350 bar pressure in a chloride-rich environment, where Monel K500 was selected for its resistance to stress corrosion cracking and hydrogen embrittlement.

• Sour Gas Service

Monel K500 is listed in NACE MR0175 for oil and gas service and is approved for sour gas service applications. It is used in sour gas wellhead components and valve stems where H₂S concentrations exceed 2,500 ppm. The alloy's natural resistance to hydrogen embrittlement makes it suitable for sour service environments.

As a professional supplier of high‑performance nickel‑copper and copper‑alloy materials, LUOYANG HONGSHENG TRADING CO., LTD provide customized Monel K500 UNS N05500 products specially oriented for oil‑and‑gas industry. We can process bars, plates, seamless tubes and drawing‑based semi‑finished blanks with different sizes, heat‑treatment status and cutting requirements.

We strictly implement corresponding ASTM standards for each product form. Mill Test Certificates are issued for every batch. Third‑party inspection by SGS, BV, TUV can be arranged in advance upon your demand.

We have accumulated rich export experience serving petroleum, marine and chemical customers across Russia, Czech Republic, South Korea and other regions, offering material‑selection suggestions, flexible customized processing and competitive factory prices.

With our full customization capabilities – from material selection and heat treatment to precision machining and full documentation – we deliver Monel K500 components that meet your exact specifications, every time. Our ISO-certified quality systems, global export track record, and proven customer success stories (including 40% longer service life and 35% better corrosion resistance) demonstrate our commitment to excellence.

If you require customized Monel K500 nickel‑copper alloy for oil and gas projects, please send your drawings, dimensions, temper requirements and quantity for a detailed quotation.

Get Quote

Company Capability



Seamless Pipe Production Line

Automatic Cold Drawing Line For Precision Superalloy And Copper Alloy Bars

250KG Vacuum Induction Melting Furnace (VIM)

Rotating+Passing Eddy Current Flaw Detector

Electron Microscope

German Spike Spectral Analyzer

Company Strengths

• Advanced melting and processing capabilities – vacuum induction melting (VIM) and VAR furnaces
• Full product range – round bars, hex bars, forgings, plates, tubes, strips, and wire
• ISO 9001:2015 certified quality management system
• Full traceability – material test certificates (MTC) with EN 10204 3.1/3.2
• Third-party inspection – SGS, TÜV, BV, DNV available
• Global export with fast delivery and competitive factory‑direct pricing
• Custom processing – drilling, turning, tapping, threading, CNC shapes, flanges, and more

Why Monel K500 is the Right Choice

Q1:What is What is UNS N05500 Monel K500 Nickel‑Copper Alloy, and why is it widely used in oil and gas industry?

A:Monel K500 is a precipitation-hardened nickel-copper alloy upgraded from Monel 400. By adding aluminum and titanium and applying strict age-hardening heat treatment, it achieves much higher tensile strength, yield strength and fatigue resistance while retaining excellent resistance to seawater, brine, and mild sour gas corrosion. For oilfield downhole tools, subsea pump parts and high-load fasteners where Monel 400 strength is insufficient, customized Monel K500 is the most reliable long-term solution.

Q2:What ASTM standards do your Monel K500 products follow?

A:We adopt industry-standard specifications strictly by product shape to ensure technical accuracy:

• Monel K500 Bar / Rod: ASTM B865
• Monel K500 Plate / Sheet: ASTM B127
• Monel K500 Seamless Tube / Pipe: ASTM B165

Custom machined blanks and special profiles are produced according to customer drawings with confirmed technical tolerances.

Q3:What customized services do you provide for Monel K500 oil & gas parts?

A:We offer full-custom solutions for petroleum and offshore projects, including custom sizes, non-standard lengths, reserved machining allowance, age-hardened temper control, cutting, forging and semi-finished blank processing. We support mixed orders of bar, tube and plate to help clients complete one-stop procurement for different downhole and subsea components.

Q4: Does Monel K500 perform better than Monel 400 for offshore service?

A:Yes. Monel 400 offers great corrosion resistance but limited mechanical strength. Under continuous torsion, vibration, high-pressure brine and cyclic fatigue loads in oilfield environments, Monel 400 is prone to deformation and fatigue failure. Custom age-hardened Monel K500 improves mechanical strength by nearly 3 times and provides excellent anti-fatigue performance, making it ideal for high-reliability oil and gas critical parts.

Q5:What oil and gas applications is customized Monel K500 suitable for?

A:It is widely used for harsh-condition petroleum components:

• Subsea pump shafts and valve stems
• Downhole tool structural parts
• High-strength corrosion-resistant oilfield fasteners and bolts
• Offshore platform heat exchanger components
• Sour service and brine environment mechanical parts

Q6:What quality certificates and test reports can you provide?

A:Every batch of Monel K500 materials comes withofficial Mill Test Certificate (MTC), including chemical composition, mechanical properties and heat treatment records. Third-party inspection reports (SGS, BV, TÜV, ISO 17025 laboratory) such as PMI testing, hardness testing and salt spray corrosion testing are available on customer request for oilfield quality audit.

Q7:Why source customized Monel K500 from your company instead of multiple suppliers?

A:Most suppliers only provide standard Monel K500 bars and lack custom tube, plate and blank processing capacity. Splitting orders leads to inconsistent heat treatment quality, different inspection standards, repeated incoming QC and longer lead time. We support multi-shape customized one-stop supply with unified batch traceability, complete documents and stable quality, greatly simplifying your oil project procurement and quality management.

Q8:Can you supply small-batch prototype orders and large-batch bulk orders?

A:Yes. We support flexible order plans, including small-batch custom blanks for prototype testing and mass bulk supply for continuous oilfield production. Stable stock of standard sizes and mature custom processing capacity ensure fast delivery for both trial and batch orders.

Q9:Do you have real oil and gas project cases for Monel K500?

A:Yes. We have served offshore equipment manufacturers with customized Monel K500 bars and tubes for subsea pump shaft components. Our customized solution solved material deformation and corrosion risks, shortened customer procurement cycle and achieved stable repeated bulk orders for long-term oilfield manufacturing.

Q10: Can I request samples before placing a bulk order?

A: Absolutely. We offer sample quantities for customer evaluation. Please let us know your required specifications (diameter, wall thickness, length, and surface condition), and we will arrange shipment promptly. For new customer we need you pay for the sample costs, as old customer sample costs are typically credited against your next bulk order.

Q11: What is the Minimum Order Quantity (MOQ)?
A: Normally MOQ is 200kg, We always expect more opportunities with you. But for some special material or special size let's communicate the actual status.

Q12: What is your lead time?
A: For standard sizes in stock, we ship within 10-15 working days. For custom sizes or normalized heat treatment, lead time is typically 30-40 working days (depending on specifications and quantity). We always provide a clear delivery schedule before order confirmation and strictly adhere to it.

Q13: What payment terms do you accept?
A: We accept T/T, L/C, and other common methods. For new customers, we usually require 50% deposit and 50% balance before shipment. Flexible terms can be negotiated for long-term partners

Q14: What if I find quality issues after receiving the goods?
A: We provide a 100% quality guarantee. If any non-conformity is found, please provide photos and test data within 7 working days of receipt. We will respond within 48 hours and agree on replacement, return, or compensation terms.
